5000W SMD Transient Voltage Suppressors Diodes 5.0SMDJ Series

Description of 5000W SMD Transient Voltage Suppressors Diodes 5.0SMDJ Series
The 5000W SMD Transient Voltage Suppressors Diodes 5.0SMDJ Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Features of 5000W SMD Transient Voltage Suppressors Diodes 5.0SMDJ Series
Very fast response time
Matte tin lead–free Plated
Halogen free and RoHS compliant
Low incremental surge resistance
Typical IR less than 5μA above 19V
Compatible with industrial standard package DO-214AB
For surface mounted applications to optimize board space
5000W peak pulse power capability with at 10/1000μs waveform,repetition rate (duty cycle): 0.01%
High temperature soldering:260°C/ 10 seconds at terminals

Description

The 5000W SMD Transient Voltage Suppressors Diodes 5.0SMDJ Series are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and transient High power, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size and other advantages, package: SMC/DO-214AB, voltage range: 11~440V.

5000W SMD Transient Voltage Suppressors Diodes 5.0SMDJ Series
