Description of 20000W High Power DIP Transient Voltage Suppressors Diodes 20KPA Series
The 20000W High Power DIP Transient Voltage Suppressors Diodes 20KPA Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.
Features of 20000W High Power DIP Transient Voltage Suppressors Diodes 20KPA Series
Fast response time
Matte tin lead–free Plated
Low incremental surge resistance
Halogen free and RoHS compliant
Typical IR less than 2μA above 40V
Compatible with industrial standard package P600
For surface mounted applications to optimize board space
20000W peak pulse power capability with at 10/1000μs waveform, repetition rate (duty cycle): 0.01%
High temperature soldering guaranteed:260°C/ 10 seconds
The 20000W High Power DIP Transient Voltage Suppressors Diodes 20KPA Series are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and transient The advantages of high power, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size, etc. Package: P600, voltage: 20 ~ 300V.
