1500W DIP Transient Voltage Suppressors Diodes 1.5KE Series

Description of 1500W DIP Transient Voltage Suppressors Diodes 1.5KE Series
The 1500W DIP Transient Voltage Suppressors Diodes 1.5KE Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Features of 1500W DIP Transient Voltage Suppressors Diodes 1.5KE Series
Fast response time
Matte tin lead–free Plated
Low incremental surge resistance
Halogen free and RoHS compliant
Typical IR less than 1μA above 12V
Compatible with industrial standard package DO-201
For surface mounted applications to optimize board space
1500W peak pulse power capability with at 10/1000μs waveform,repetition rate (duty cycle): 0.01%
High temperature soldering guaranteed:260°C/ 10 seconds

Description

The 1500W DIP Transient Voltage Suppressors Diodes 1.5KE Series are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and instantaneous High power, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size, etc., package: DO-201, voltage range: 5.8~410V .

1500W DIP Transient Voltage Suppressors Diodes 1.5KE Series
