600W SMD Transient Voltage Suppressors Diodes SMBJ Series

Description of 600W SMD Transient Voltage Suppressors Diodes SMBJ Series
The 600W SMD Transient Voltage Suppressors Diodes SMBJ Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Features of 600W SMD Transient Voltage Suppressors Diodes SMBJ Series
Very fast response time
Halogen free and RoHS compliant
Low incremental surge resistance
Optimized for LAN protection applications
Matte tin lead–free Plated
Typical IR less than 1μA above 10V
For surface mounted applications to optimize board space
600W peak pulse power capability with at 10/1000μs waveform, repetition rate (duty cycle): 0.01%
High temperature soldering:260°C/10 seconds at terminals

Description

The 600W SMD Transient Voltage Suppressors Diodes SMBJ Series are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and transient power. Large, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size, etc., package: SMB/DO-214AA, voltage range: 5.0~500V .

600W SMD Transient Voltage Suppressors Diodes SMBJ Series
