Description of 400W SMD Transient Voltage Suppressors Diodes SMAJ Series
The 400W SMD Transient Voltage Suppressors Diodes SMAJ Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.
Features of 400W SMD Transient Voltage Suppressors Diodes SMAJ Series
Fast response time
Low incremental surge resistance
Matte tin lead–free Plated
Halogen free and RoHS compliant
Typical IR less than 1μA above 10V
Compatible with industrial standard package DO-214AC
For surface mounted applications to optimize board space
400W peak pulse power capability with at 10/1000μs waveform, repetition rate (duty cycle): 0.01%
High temperature soldering:260°C/10 seconds at terminals
The 400W SMD Transient Voltage Suppressors Diodes SMAJ Series are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and transient power. Large, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size, etc., package: SMA/DO-214AC, voltage range: 5～440V .
