3000W SMD Transient Voltage Suppressors Diodes SMDJ Series

Description of 3000W SMD Transient Voltage Suppressors Diodes SMDJ Series
The 3000W SMD Transient Voltage Suppressors Diodes SMDJ Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Features of 3000W SMD Transient Voltage Suppressors Diodes SMDJ Series
Low profile package
Matte tin lead–free Plated
Halogen free and RoHS compliant
Low incremental surge resistance
Typical IR less than 2μA above 10V
Compatible with industrial standard package DO-214AB
For surface mounted applications to optimize board space
3000W peak pulse power capability with at 10/1000μs waveform, repetition rate (duty cycle): 0.01%
High temperature soldering:260°C/10 seconds at terminals

Description

The 3000W SMD Transient Voltage Suppressors Diodes SMDJ Series are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and transient High power, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size and other advantages, package: SMC/DO-214AB, voltage range: 5.0~440V.

3000W SMD Transient Voltage Suppressors Diodes SMDJ Series
